120W / 140W GaN PD Chargers 120W / 140W Max - MK-GaN PD-120W 140W Max

Inquiry

Product Variants

Specifications

input
100-240V~50/60Hz 0.5A
output
3-48Vdc, 10-2500mA
AC plug
EU/KC/UK/AU/US/JP/AR/CN
DC plug
Barrel Plug / Other Options
DC wire
Round / Flat
Length
1.2M, 1.5M, 2M, etc
certifications
UL, CE, FCC, GS, KC, KCC, UKCA, cUL, ETL, SAA, C-Tick, RCM, PSE, S-mark, CCC, EAC, CB, BIS, PSB, BSMI

Plug List of Output Cable

Plug TypeSpecificationOutline / Drawing
Stripped & TinnedNCStripped and tinned cable outline
Barrel Type5.5x2.1Barrel type outline for 5.5x2.1, 5.5x2.5, 4.75x1.7, and 4.0x1.7
5.5x2.5
4.75x1.7
4.0x1.7
3.5x1.35Barrel type outline for 3.5x1.35, 2.35x0.7, and 6.3x3.0
2.35x0.7
6.3x3.0
Barrel Type6.5x1.4Barrel type outline for 6.5x1.4
Barrel Type Right Angle5.5x2.1Right angle barrel type outline
5.5x2.5
4.75x1.7
4.0x1.7
3.5x1.35
2.35x0.7
6.3x3.0
6.5x1.4
Din (male)3PinDin male plug outlines from 3Pin to 8Pin
4Pin
5Pin(180)
5Pin(240)
6Pin
7Pin
8Pin
Plug TypeSpecificationOutline / Drawing
Power-Mini Din (male)3Pin (Molding)Power-Mini Din male 3Pin molding outline
4Pin (Molding)Power-Mini Din male 4Pin molding outline
3Pin (Assembly/Lock Type)Power-Mini Din male 3Pin assembly lock type outline
4Pin (Assembly/Lock Type)Power-Mini Din male 4Pin assembly lock type outline
Interchangeable Connector2PinInterchangeable connector 2Pin outline
2PinInterchangeable connector 2Pin outline
3PinInterchangeable connector 3Pin outline
Switchcraft Locking TypeA:5.5, B:2.5 C:0.375"(9.52mm)Switchcraft locking type outline
A:5.5, B:2.5 C:0.475"(12.06mm)
A:5.5, B:2.1 C:0.375"(9.52mm)
A:5.5, B:2.1 C:0.475"(12.06mm)
DC plug with ScrewA:5.5, B:2.1/2.5, C:7.5DC plug with screw outline
A:5.5, B:2.1/2.5, C:10.1
Cigarette Lighter-Cigarette lighter plug outline
USB Type C-USB Type C plug outline
