Desktop Type Power Adapters 36W / 65W / 120W Max - MKE

MKE is a 36W desktop AC-to-DC power adapter with a factory-selected DC output. Please match the ordered voltage, current, connector and application requirements; the family name alone does not specify a complete order configuration.

MKE lists the following factory-configured output options: 12V 2A, 12V 3A, 24V 1.25A, 24V 1.5A, 9V 4A, 9V 3A, 5V 4A, 5V 5A, 15V 1.5A, 15V 2A, 36V 1A, 48V 0.75A. Each voltage/current pair is a separate configuration; these are not simultaneous outputs or user-adjustable settings.

No. The MKE range of 3-48Vdc and current field of 10-8000mA describe a product family, not every possible combination. The approved voltage/current pair, total power, cable capacity and temperature limits must all be met. Requests outside the confirmed configuration need engineering review.

MKE may be suitable if its approved DC voltage, available current, connector dimensions and polarity match your equipment. Please send the original label, application, steady load and startup current. A matching wattage or plug appearance alone is insufficient.

The supplied MKE product information does not state an AC input voltage or frequency range. Please request the exact model nameplate and approved input specification before using it on your local mains supply. For high-power operation, also confirm whether output derating applies at the intended input voltage.

MKE lists C6, C8 and C14 inlet options, with regional AC cords including 1.5m and 2m lengths. Please confirm which inlet is approved for the selected power and insulation class, whether protective earth is required, and whether the AC cord is included in the price.

The illustrated MKE enclosure is 82 x 45.2 x 30 mm. Confirm the dimension reference, tolerances, plug projection and cable-exit clearance against the approved drawing. These reference dimensions do not establish the final packed size or weight.

MKE lists DC barrel and other optional terminations. Please specify outer diameter, inner diameter, insertion length, straight or right-angle form, molding clearance and center-positive or center-negative polarity. For DIN, aviation, magnetic, bare-wire or other connectors, provide a drawing or pinout for feasibility and current-rating review.

MKE: The listed DC cable options include 1.2m, 1.5m and 2m, with round or flat constructions. For a different length, wire gauge, ferrite, braid or cable material, send the full requirement. Cable resistance, voltage at the device under load, temperature rise, connector assembly and material MOQ need confirmation before approval.

A matching voltage does not confirm that MKE is a battery charger. Please specify battery chemistry, series count, capacity, BMS, CC/CV current and voltage, termination current and indicator behavior. Battery charging requires a separately confirmed charging design; an ordinary constant-voltage adapter must not be offered as equivalent.

Please provide the steady load, startup waveform, peak current duration and duty cycle for MKE. Selection must account for the startup demand and the adapter protection behavior. We can evaluate the application and sample test, but the nominal wattage alone does not confirm successful starting.

The MKE listing mentions CE, GS, KC, UKCA, UL/CUL, ETL, FCC, SAA, PSE, CCC, EAC, CB, BIS and PSB. Availability must be checked for the exact model suffix, output, plug and destination market. Please tell us the required documents so our team can confirm the applicable certificate/report numbers and matching label. The general list does not confirm every mark on every variant.

Exact values and test conditions are not provided in the available MKE sheet. Please specify your ripple/noise limit, input voltage, load, measurement bandwidth, standby-power target and required protection behavior. Our team must confirm them with the model-specific specification or test report before making a performance commitment.

Please provide the ambient temperature, ventilation, load profile, operating duration and acoustic acceptance conditions for MKE. Continuous-load capability, derating, case temperature and noise need confirmation for the chosen configuration and installation. We cannot promise a temperature limit or noise-free operation without the agreed test conditions.

The available MKE information does not state an IP rating or outdoor-use approval. Please specify the required ingress-protection level and environment for review. A waterproof connector, cable treatment or moisture-resistant carton does not establish a waterproof adapter enclosure.

Yes, OEM and ODM are listed for MKE. Please send the logo artwork, size, placement and preferred marking method for review. Printing, laser marking, labels and neutral-brand requests depend on the approved housing and order configuration. Required rating and traceability information must remain consistent with the approved product.

A color or finish change can be requested for MKE, but availability, resin, tooling, MOQ, cost and lead time need confirmation. The listed standard-order MOQ does not automatically apply to a custom color. Please send the color reference and quantity per color; a sample color is not a confirmed mass-production commitment.

Packaging customization can be reviewed for MKE. Specify retail box or bulk packing, included cords/cables/plug heads, logo artwork, manual languages, barcode/FNSKU, carton quantity and any QR code. Please approve the packaging artwork and packing list before production; fees and MOQ are quoted for the selected design.

The listed MOQ for MKE is 500 pieces. Samples, trial orders, custom colors, packaging and mixed output/plug versions need separate confirmation. Please provide the quantity per configuration; a combined order total does not automatically satisfy the MOQ for every SKU or custom material.

The reference price listed for MKE is USD 2.39-2.99 / piece. This is not a final order quotation. The confirmed price depends on the output and plug version, cables/accessories, logo, packaging, required documentation and quantity. Please request a current quotation that states what is included and the shipping/tax terms.

The listed lead time for MKE is 20-40 days. The actual schedule depends on the approved specification, artwork, sample status, material availability and order quantity. Please confirm the production start point and whether transit time is included in the quotation; a smaller order is not automatically ready to ship.

Please request a sample of MKE in the intended voltage/current, plug, connector and cable configuration, with the desired branding if relevant. Sample availability, quantity, charges and dispatch time require confirmation. Test it with your actual device before approving the production specification.

The supplied MKE product information lists a 3 years warranty. Please confirm the start date, coverage of the adapter and bundled cables, exclusions and claim/remedy process in the order terms. The product-specific order agreement should be used when other general or historical warranty periods differ.

Please send the full MKE configuration: destination market, application, output or charging profiles, AC plug/inlet, output connector and polarity/pinout where applicable, cable details, quantity per version, required reports, logo and packaging. Approve the final specification, drawing, sample, label and packing list before mass production. Any later change needs a new written confirmation.
