Interchangeable Plug Power Adapters 15W / 18W Max - MKA-D

Inquiry

Product Variants

Specifications

input
100-240V~50/60Hz 0.5A
output
3-48Vdc, 10-2500mA
AC plug
EU/KC/UK/AU/US/JP/AR/CN
DC plug
Barrel Plug / Other Options
DC wire
Round / Flat
Length
1.2M, 1.5M, 2M, etc
certifications
UL, CE, FCC, GS, KC, KCC, UKCA, cUL, ETL, SAA, C-Tick, RCM, PSE, S-mark, CCC, EAC, CB, BIS, PSB, BSMI

Additional Specifications

Universal input100-240V~50/60Hz
Input current0.4A Max
General outputs
3V 1A5V 0.3A6V 0.3A10V 0.5A15V 0.5A
3.3V 1A5V 0.5A6V 0.5A10V 0.8A15V 0.8A
4.2V 1A5V 0.6A6V 0.8A10V 1A15V 1A
4.2V 1.5A5V 0.7A6V 1A10V 1.5A18V 0.5A
4.2V 2A5V 0.8A6V 1.2A12V 0.3A18V 0.8A
7.5V 1A5V 0.9A6V 1.5A12V 0.5A19V 0.5A
7.5V 1.5A5V 1A6V 2A12V 0.4A19V 0.7A
8.4V 1A5V 1.2A6V 2.5A12V 0.6A20V 0.5A
8.4V 1.5A5V 1.5A9V 0.5A12V 0.7A21V 0.5A
12.6V 0.5A5V 2A9V 0.8A12V 0.8A24V 0.5A
12.6V 0.8A5V 2.1A9V 1A12V 1A36V 0.3A
16.8V 0.5A5V 2.4A9V 1.2A12V 1.2A40V 0.3A
16.8V 0.7A5V 2.5A9V 1.5A12V 1.25A48V 0.25A
DC wire
Flat cable / round cableL=1M / 1.5M / 2M...
Support For Custom SPEC
