POE Power Adapters MK-P (POE Power Adapters) - MK-P

MK-P is a wall-plug PoE power adapter for compatible network equipment, rated up to 36W. It has separate LAN and PoE sockets. The powered device must match the selected output voltage, power method and pin assignment.

MK-P lists factory-selected 24-48V DC options, with current up to 750mA and a 36W maximum. These are not interchangeable settings or arbitrary combinations: 48V at 0.75A is 36W, while 24V at 0.75A is 18W. Confirm the exact output version before connection.

The available MK-P information does not confirm active/passive operation or an IEEE 802.3 protocol. Please provide the powered-device model and required standard. A 48V label or LAN/PoE socket alone does not prove negotiation support; obtain the matching model specification before use.

The MK-P pinout is not specified in the supplied product information. Please confirm which pairs carry power and data, the polarity and the powered-device wiring. A passive arrangement such as pins 4/5 positive and 7/8 negative must be treated as a requested configuration, not an established feature.

The Ethernet data rate for MK-P is not stated. Please specify 100Mbps or 1000Mbps and the required cable/pair arrangement so our team can confirm the correct version. A similar enclosure or connector does not establish Gigabit capability.

The supplied MK-P specification is limited to 24-48V and up to 36W. Requests for higher voltage, higher power or PoE++ require a separately approved product. Please provide the load, protocol and cable length for model selection.

MK-P is described with AC mains input, not 12V DC input. A DC-input PoE project needs a separate converter design. Please specify the DC input range, required PoE voltage/power, isolation and redundancy requirements.

After confirming the MK-P electrical specification and pinout, use the LAN port for the network connection and the PoE port for the compatible powered device. Confirm the port labels on the delivered unit; do not connect an unverified passive power output to equipment that is not compatible.

MK-P lists 100-240V AC input, 50/60Hz. Select the correct plug and approved configuration for the destination market. The AC input range does not make its DC output voltage adjustable.

MK-P lists regional plug options: EU/UK. Specify the exact country and plug geometry, including round-pin diameter where relevant. Multiple regional options do not establish interchangeable or folding pins; confirm the required construction before ordering.

The illustrated MK-P enclosure is 82.5 x 47 x 30.7 mm. Confirm the dimension reference, tolerances, plug projection and cable-exit clearance against the approved drawing. These reference dimensions do not establish the final packed size or weight.

The MK-P listing mentions CE, GS, KC, UKCA, UL/CUL, ETL, FCC, SAA, PSE, CCC, EAC, CB, BIS and PSB. Availability must be checked for the exact model suffix, output, plug and destination market. Please tell us the required documents so our team can confirm the applicable certificate/report numbers and matching label. The general list does not confirm every mark on every variant.

Exact values and test conditions are not provided in the available MK-P sheet. Please specify your ripple/noise limit, input voltage, load, measurement bandwidth, standby-power target and required protection behavior. Our team must confirm them with the model-specific specification or test report before making a performance commitment.

Please provide the ambient temperature, ventilation, load profile, operating duration and acoustic acceptance conditions for MK-P. Continuous-load capability, derating, case temperature and noise need confirmation for the chosen configuration and installation. We cannot promise a temperature limit or noise-free operation without the agreed test conditions.

The available MK-P information does not state an IP rating or outdoor-use approval. Please specify the required ingress-protection level and environment for review. A waterproof connector, cable treatment or moisture-resistant carton does not establish a waterproof adapter enclosure.

Yes, OEM and ODM are listed for MK-P. Please send the logo artwork, size, placement and preferred marking method for review. Printing, laser marking, labels and neutral-brand requests depend on the approved housing and order configuration. Required rating and traceability information must remain consistent with the approved product.

A color or finish change can be requested for MK-P, but availability, resin, tooling, MOQ, cost and lead time need confirmation. The listed standard-order MOQ does not automatically apply to a custom color. Please send the color reference and quantity per color; a sample color is not a confirmed mass-production commitment.

Packaging customization can be reviewed for MK-P. Specify retail box or bulk packing, included cords/cables/plug heads, logo artwork, manual languages, barcode/FNSKU, carton quantity and any QR code. Please approve the packaging artwork and packing list before production; fees and MOQ are quoted for the selected design.

The listed MOQ for MK-P is 500 pieces. Samples, trial orders, custom colors, packaging and mixed output/plug versions need separate confirmation. Please provide the quantity per configuration; a combined order total does not automatically satisfy the MOQ for every SKU or custom material.

The reference price listed for MK-P is USD 2.50-3.50 / piece. This is not a final order quotation. The confirmed price depends on the output and plug version, cables/accessories, logo, packaging, required documentation and quantity. Please request a current quotation that states what is included and the shipping/tax terms.

The listed lead time for MK-P is 20-40 days. The actual schedule depends on the approved specification, artwork, sample status, material availability and order quantity. Please confirm the production start point and whether transit time is included in the quotation; a smaller order is not automatically ready to ship.

Please request a sample of MK-P in the intended voltage/current, plug, connector and cable configuration, with the desired branding if relevant. Sample availability, quantity, charges and dispatch time require confirmation. Test it with your actual device before approving the production specification.

The supplied MK-P product information lists a 3 years warranty. Please confirm the start date, coverage of the adapter and bundled cables, exclusions and claim/remedy process in the order terms. The product-specific order agreement should be used when other general or historical warranty periods differ.

Please send the full MK-P configuration: destination market, application, output or charging profiles, AC plug/inlet, output connector and polarity/pinout where applicable, cable details, quantity per version, required reports, logo and packaging. Approve the final specification, drawing, sample, label and packing list before mass production. Any later change needs a new written confirmation.
